Electric pallet truck with lithium-Ion battery 2 tons HanseLifter E-LI-MOVER20

New

HanseLifter E-LI-MOVER20 2-metric-ton Electric Pallet Truck with Lithium-Ion Battery

Based on 0 reviews. - Write a review

SKU: BD71681
SKU:: GE0081869

2,049.00 €

Hanselifter

Prices shown include tax

Add to Cart

Send Message

Description

HanseLifter E-LI-MOVER20 2-metric-ton Electric Pallet Truck with Lithium-Ion Battery

Country of origin: Germany; warranty period: 24 months

The HanseLifter E-LI-MOVER20 is a professional electric pallet truck with a replaceable lithium-ion battery, designed for the efficient lifting and transport of heavy pallets in warehouses, production facilities, retail locations, logistics centers, and loading areas. A lifting capacity of 2,000 kg allows for the reliable transport of heavy Euro pallets and other standard pallets, while the electric drive for travel and lifting reduces the physical strain on employees and increases productivity. The lifting range of 82 to 187 mm ensures convenient pallet lifting and handling, while the compact design and multifunctional control handle allow for precise maneuvering in confined workspaces. The replaceable 48 V lithium-ion battery makes it easy to organize work across different shifts, and the external charger allows the battery to be charged from a standard electrical outlet. The robust construction, durable polyurethane wheels, and integrated safety features ensure smooth, reliable, and efficient daily use.

Technical Specifications:

Lifting capacity: 2,000 kg
Drive type: electric travel and electric lift
Control type: pedestrian-controlled
Drive motor power: 0.7 kW
Lifting motor power: 0.7 kW
Motor control type: direct current (DC)
Distance to load center of gravity: 600 mm
Load distance: 950 mm
Wheelbase: 1210 mm
Lifting range: 82–187 mm
Maximum fork lift height: 187 mm
Minimum fork height: 82 mm
Fork stroke: 105 mm
Fork length: 1150 mm
Fork dimensions: 50 × 150 × 1,150 mm
Outer fork width: 560 mm
Frame length without forks: 430 mm
Handle height: 750–1,190 mm
Front wheel size: 150 × 65 mm
Rear wheel size: 80 × 60 mm
Tine wheel configuration: tandem
Wheel material: polyurethane (PU)
Rear track width: 410 mm
Clearance at the center of the wheelbase: 25 mm
Turning radius: 1390 mm
Working passage width with an 800 × 1200 mm pallet: 2055 mm
Travel speed with load: 4 km/h
Travel speed without load: 4.5 km/h
Lifting speed with/without load: 17 / 23 mm/s
Lowering speed with load / without load: 35 / 53 mm/s
Maximum climbability with load: 8%
Maximum gradeability without load: 16%
Braking system: electromagnetic
Crawl mode: available
Auto-shutdown function: yes
Battery type: lithium-ion (Li-ion)
Battery voltage: 48 V
Battery capacity: 15 Ah
Battery weight: 5 kg
Replaceable battery: Yes
Charger: external
Charger power supply: 230 V
Noise level at the operator’s station: 74 dB(A)
Controls: electric lifting, lowering, and travel

The HanseLifter E-LI-MOVER20 2-metric-ton is the right choice for companies that need a reliable, compact electric pallet truck designed for intensive daily use. With a lifting capacity of 2,000 kg, a lifting range of 82–187 mm, electric drive for both travel and lifting, and a multifunctional control handle, it enables more efficient pallet loading, unloading, and transport operations. A replaceable lithium-ion battery, durable polyurethane wheels, a compact design, and integrated safety features ensure convenient, efficient, and long-lasting use in warehousing, manufacturing, retail, and logistics.

Electric pallet lifting, lowering, and transport
A lifting capacity of 2,000 kg allows for the transport of heavy storage and industrial pallets
A lifting range of 82 to 187 mm allows for the convenient lifting and moving of standard pallets
The electric drive reduces physical effort when transporting heavy loads
The electric lifting mechanism allows the load to be raised and lowered without using a manual hydraulic pump
A 0.7 kW travel motor ensures smooth and efficient pallet transport
The 0.7 kW lift motor enables reliable lifting of heavy loads
The multifunctional control handle allows for convenient control of travel, lifting, and lowering
The ergonomic control handle facilitates maneuvering and precise positioning of the truck
The slow-speed mode allows for precise maneuvering in tight spaces and loading areas
The ability to maneuver with the control handle in a vertical position makes it easier to work in confined spaces
The replaceable lithium-ion battery ensures flexible and convenient use of the equipment
The battery can be quickly replaced without the need for special tools
The automatically locking battery handle facilitates safe removal and insertion
Lithium-ion technology features high energy density, low self-discharge, and a long service life
The battery is suitable for top-up charging during work breaks
The external battery charger allows for convenient charging from a standard 230 V electrical outlet
A spare lithium-ion battery is available upon separate request
The integrated auto-shutdown function helps reduce unnecessary energy consumption
The electromagnetic brake ensures controlled stopping of the cart
An emergency stop switch integrated into the control handle increases workplace safety
Tandem casters help distribute the load more evenly and navigate floor joints and minor unevenness more smoothly
Polyurethane casters feature quiet rolling, wear resistance, and are suitable for smooth industrial floors
The compact design is optimized for use in narrow warehouse aisles and confined spaces
The 1,150 mm-long forks and 560 mm outer fork width are designed for transporting standard Euro pallets
A maximum travel speed of 4.5 km/h allows for efficient transport of loads within the warehouse
The truck can handle slopes of up to 8% when loaded and up to 16% when unloaded
A low net weight of 129 kg makes the cart easy to transport and use in different work areas
The robust construction is designed for intensive daily use
An integrated diagnostic port simplifies technical condition checks and equipment maintenance
Suitable for use in warehouses, manufacturing facilities, retail locations, logistics centers, and vehicle loading areas

Length: 1580 mm
Width: 590 mm
Height: 1,190 mm
Weight: 129 kg

HanseLifter E-LI-MOVER20 Electric Pallet Truck x 1
Replaceable 48 V / 15 Ah lithium-ion battery x 1
External battery charger x 1
Multifunction control handle x 1
Integrated electric lifting mechanism x 1
Tandem swivel casters x 1
Electromagnetic braking system x 1
