Metal sanding machine with dust collector HOLZMANN

Metal Sanding Machine with Dust Collector HOLZMANN

Country of origin: Austria, warranty period - 24 months

The HOLZMANN metal sanding machine with a dust collector is an excellent choice for precise and efficient metal sanding tasks. The two-speed sanding belt allows optimal adjustment of the machine to suit specific needs. Sanding can be performed either on the worktable with a pressure roller (Ø200 mm) or on the flat surface with a graphite underlay, ensuring outstanding results. The adjustable inclination of the machine body provides comfortable operation, while the integrated dust collector helps maintain a clean workshop environment.

Functions:

• High belt speed ensures optimal sanding results
• Convenient belt replacement due to the quick-clamp mechanism
• Pivoting sanding system with a quick fastening lever
• Powerful motor delivers constant torque and excellent sanding performance
• Rubberized sanding rollers and graphite support pads ensure smooth and precise belt movement
• Fine adjustment knob guarantees perfectly balanced belt operation
• Integrated dust collection system keeps the workspace clean

Technical Specifications:

Motor:

• Power (S1): 4000 W / 750 W
• Voltage: 400 V / 3 / 50 Hz

Dimensions:

• Table size: 480 x 150 mm
• Dust extraction port diameter: 2 x Ø100 mm
• Overall dimensions: 1300 x 600 x 970 mm

Dust Collector:

• Suction capacity: 850 m³/h
• Chip bag diameter: Ø320 mm
• Chip bag length: 650 mm

Sanding:

• Belt dimensions: 2000 x 150 mm
• Belt speed: 15 m/s | 30 m/s

Noise Level and Vibration:

• Sound pressure level: 72.5 dB(A)

Weight:

• Gross weight: 117 kg
• Net weight: 94 kg

Packaging:

• Packaging width: 590 mm
• Packaging length: 750 mm
• Packaging height: 1130 mm
