Mobile diesel generator BD9500SE, 7 kW

Mobile Diesel Generator BD9500SE, 7 kW

Country of origin: China, warranty period - 24 months

The BD9500SE mobile diesel generator is a powerful, reliable, and economical power source designed for both domestic and professional use. With a continuous output of 7 kW and the option to select 230 V or 400 V voltage, this generator is ideal for use on construction sites, at events, or as a backup power supply for homes. The electronic start system, digital display, heater, and high-quality wheels ensure convenient operation even in demanding conditions.

Functions:

• Electronic start system
• Selectable 230 V or 400 V output
• Digital information display
• Preheating function for cold temperatures
• Compatible with ATS automatic transfer switch
• Rubber wheels for easy transportation
• Integrated automatic circuit breakers
• High-quality synchronous generator with AVR system
• Uses 10W/30SAE engine oil

Technical specifications:

• Maximum output (stand-by): 7.5 kW / 9.4 kVA
• Continuous output (prime): 7 kW / 8.75 kVA
• Voltage: 230 / 400 V
• Frequency: 50 Hz
• Number of phases: 3 phases (selectable)
• AVR voltage regulation accuracy: ± 0.5%
• DC output: 12 V / 8.3 A
• Noise level (7 m): 69–72 dB
• Cooling system: air-cooled
• Number of cylinders: 1
• Cycle: 4-stroke
• Engine speed: 3000 rpm
• Engine model: 195FC
• Displacement: 531 cm³
• Piston diameter and stroke: 95 x 75 mm
• Fuel consumption at 100% load: 1.9 l/h
• Fuel consumption at 75% load: 1.43 l/h
• Fuel consumption at 50% load: 0.952 l/h
• Fuel tank capacity: 16 l
• Operating time: 7 h
• Oil capacity: 1.65 l
• Oil type: 10W/30SAE
• Operating temperature: from –15 °C to +40 °C
• Battery capacity: 30 Ah
• Power output sockets: 2 pcs
• Protection class: IP23
• Package dimensions: 950 x 550 x 760 mm
• Weight: 163 kg

Model specifications:

• Model: BD9500SE
• Power: 7000 W
• Current in single-phase mode (230V): 30.4 A
• Current in three-phase mode (400V): 10.1 A

Scope of delivery:

• Basic maintenance tools
• Power plugs x 2 pcs
• Starting keys x 2 pcs
• User manual
• Generator wheels x 4 pcs
