Professional diagnostic equipment AUTEL MaxiSYS MS906 MAX with Bluetooth VCI

Professional diagnostic tool AUTEL MaxiSYS MS906 MAX with Bluetooth VCI

Premium wireless diagnostic tablet with wide vehicle coverage.

The AUTEL MaxiSYS MS906 MAX is a professional 10.1-inch wireless diagnostic and service tablet designed for workshops looking for a powerful and versatile all-in-one solution. This model provides full-system diagnostics, active tests, advanced service functions and coding capabilities. The MaxiVCI V200 Bluetooth module ensures convenient operation and stable communication with the vehicle.

Why choose AUTEL MaxiSYS MS906 MAX?

• Large and user-friendly 10.1-inch display.
• Clear visuals, easy navigation and more information in one view for more efficient work.
• Universal diagnostics for vehicles manufactured from 1996 onwards.
• Compatible with US, Asian and European market vehicles, providing wide vehicle coverage.
• Full-system diagnostics and data graphs.
• Fault code reading and clearing, live data viewing and graphing for detailed diagnostics.
• 40 commonly used service functions.
• From DPF regeneration to brake bleeding – more capabilities without additional equipment.
• Bi-directional control and advanced tests.
• Active tests, coding and adaptations – OE-level functions for professional service work.
• Wireless Bluetooth VCI connection.
• The MaxiVCI V200 adapter supports standard and advanced communication protocols, ensuring convenient connection to different vehicle models.
• Cloud integration and report sharing.
• Convenient diagnostic data sharing via email or text message.

Features:

• 10.1-inch wireless professional diagnostic and service touchscreen tablet.
• Wide coverage for US, Asian and European vehicles manufactured from 1996 onwards.
• Performs diagnostics in all systems, including fault code scanning and clearing, live data viewing and graphing.
• Performs bi-directional active tests and special functions.
• Advanced service and maintenance function menu.
• Supports coding and adaptation functions.
• Includes the MaxiVCI V200 Bluetooth module, compatible with standard and advanced communication protocols.
• 128 GB internal storage and extended battery life.
• Supports battery, starter and charging system testing, as well as videoscope functionality with optional accessories.

Technical specifications:

• Model: MS906 MAX;
• Operating system: Android 10;
• Processor: octa-core processor;
• Memory: 4 GB RAM and 128 GB internal storage;
• Battery: 11,600 mAh, 3.85 V lithium-polymer battery;
• Display: 10.1-inch LCD touchscreen with 1920 × 1200 resolution;
• Rear camera: 13 MP;
• Connectivity: Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.0 BR/EDR + BLE, GPS, USB 2.0, two USB Type-A ports, one mini USB port, SD card with support up to 256 GB;
• Audio input/output: microphone, dual speakers, 3.5 mm headphone jack;
• Operating temperature: 0 °C to +50 °C;
• Storage temperature: -10 °C to +60 °C.

Supported protocols:

• ISO13400, CAN FD, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS;
• SAE-J2411, ISO-11898-2, ISO-11898-3, SAE-J2819, TP20, TP16, ISO-9141, ISO-14230;
• SAE-J2610, UART Echo Byte, SAE-J2809, SAE-J2740, SAE-J1567;
• Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, KW81, KW82;
• SAE J1708, SAE-J1850 PWM, SAE-J1850 VPW.

Who is this device for?

• AUTEL MaxiSYS MS906 MAX is ideal for professional automotive workshops, diagnostic specialists and service technicians looking for one solution for full-system vehicle diagnostics, service functions and coding capabilities. It is built for fast, accurate and efficient work without compromise.

Why buy from BalticDiag?

• BalticDiag is the only official AUTEL representative in Latvia.
• We offer original AUTEL equipment with wide vehicle coverage and software adapted for the European market.
• The device supports multiple languages, including English and Russian.
• The most popular AUTEL products are available in stock, ensuring fast delivery to customers in Latvia.
• Before purchasing, customers can visit us in person, see and test the available AUTEL diagnostic equipment.
• Our customers receive full warranty and post-warranty support.
• During repair, we provide a replacement device if the repair takes longer.

Experience the difference – work faster and smarter with one device!

• Try AUTEL MaxiSYS MS906 MAX today – contact us to receive an offer tailored to your service needs.
