Fume Extraction Unit with Replaceable Filter M2/2100 FRESHWELD

Country of origin: Turkey, warranty period – 24 months

The M2/2100 is a mobile fume and fine dust extraction unit equipped with a disposable filter and a flexible extraction arm. This unit is specially designed for use during welding and for processing unalloyed and low-alloy steel, where low to medium levels of fumes and dust are generated. The M2/2100 operates at a low noise level (72 dB), complies with European safety regulations, and ensures safe and uninterrupted operation with features like a spark arrestor, phase monitoring, and filter change indicators.

Features:

• Mobile unit with lockable caster wheels
• Easily reaches any desired area thanks to its flexible hose
• Fully complies with European Machinery Safety Regulations
• Filter change indicator ensures maintenance only when necessary
• Aluminum spark arrestor reduces the risk of fire
• If the phase sequence is incorrect or a phase is missing, the motor will not start and remains protected
• A warning lamp activates if the fan rotates in the wrong direction
• Quiet operation – only 72 dB

Technical Specifications:

• Filter: disposable cartridge type F9 (ePM1 80%, EN 779)
• Optional: E12 HEPA filter integration (≤99.99%, EN 1822)
• Noise level: 72 dB
• Extraction arm: flexible, single acrobat arm, length options available
• Power supply: 3x400V / 50Hz (other voltages available upon request)
• Power cable length: 3 meters
• Packaging: palletized with protective strap

AVAILABLE VERSIONS:
