Two-post hydraulic lift Duolift® HL 5500 Hofmann

Two-Post Hydraulic Lift Duolift® HL 5500 Hofmann

Country of origin: Italy, warranty period: 24 months

The Duolift® HL 5500 is a two-post automotive lift specifically designed for lifting medium and heavy-duty vehicles, such as long-wheelbase vans. It provides high lifting capacity and a symmetric configuration, allowing easy lifting of passenger cars, SUVs, transporters, and small vans.

Features:

• Hydraulic two-post construction – ensures reliable and smooth lifting
• High lifting capacity – up to 5,500 kg
• Fast lifting and lowering – lifting time 47 sec., lowering time 40 sec.
• Symmetric design – ensures optimal weight distribution
• Wide drive-through width – suitable for various types of vehicles
• Electrically controlled locking system – enhances operational safety
• High-quality hydraulic system – ensures reliable and trouble-free performance
• Adjustable lifting points – suitable for different vehicle types
• Durable and robust structure – provides safe and stable lifting

Technical Specifications:

• Lifting capacity: 5,500 kg
• Lifting / lowering time: 47 / 40 sec.
• Maximum lifting height: 2,020 mm
• Lowest pick-up point: 140 – 220 mm
• Diameter of pick-up pads: 120 mm
• Total height: 4,600 mm
• Automatic stop height: 4,950 mm
• Recommended installation width: 3,872 mm
• Drive-through width: 2,776 mm
• Long arms extraction: 900 – 1,900 mm
• Short arms extraction: 4,406 – 4,756 mm
• Power supply: 400-415V AC, 3-phase, 50 Hz
• Motor power: 4 kW
• Minimum ceiling height for installation: 4,650 mm

3-Stage Arms (Symmetric)

• The front and rear 3-stage arms allow perfect access to the vehicle's lifting points.

Comfort Lowering

• The lift will automatically raise slightly to release the carriage from the safety lock, then smoothly lower the vehicle.

Ergonomic Controls

• Control buttons are positioned ergonomically on the main column, with clear labels for intuitive and easy operation.

Lifting Carriage

• Enhances stability, providing a solid foundation for each lifting operation. Integrated arm lock system ensures maximum safety and reliability.

Safety Lock

• The locking mechanism remains engaged throughout the entire lifting procedure. Additionally, it can be activated at any time with a simple press of the lock button.

Secondary Control Panel

• An optional secondary control box is available, allowing lift operation from both sides.

Shut-Off Bar

• A protective shut-off bar prevents damage to the upper part of the vehicle, automatically stopping lift operation upon contact.
