Universal wireless diagnostic tool Autel MaxiDAS DS900BT

Universal Wireless Diagnostic Tool Autel MaxiDAS DS900BT

Autel MaxiDAS DS900BT is a universal and advanced diagnostic tablet that combines fast performance, comprehensive functionality, and wireless connectivity to the vehicle. Equipped with an Android system, a powerful quad-core processor, and the integrated MaxiVCI V150 adapter, this tool enables deep vehicle analysis without cables. It is ideal for both system diagnostics and service function execution — from fault code clearing to DPF regeneration.

Why Choose Autel MaxiDAS DS900BT?

• Wireless Connectivity with the Vehicle
• The included MaxiVCI V150 adapter provides seamless Bluetooth connection — enabling more mobility and a clutter-free workspace.
• Comprehensive Diagnostics in One Device
• Performs full-system fault code reading, active tests, and live data monitoring — helping you identify issues accurately and quickly.
• Advanced Service Functions
• Supports oil resets, EPB, SAS, BMS, DPF regeneration, injector coding, and more — no additional equipment needed.
• User-Friendly, Informative Display
• The 8-inch touchscreen allows you to view data in both graphical and numeric formats with clarity and ease.
• Quick Vehicle Identification
• AutoVIN technology automatically recognizes the make, model, and year of the vehicle — reducing diagnostic setup time.
• Pre- and Post-Diagnostic Reporting
• Easily generate comprehensive reports on the vehicle’s condition before and after service — ideal for transparency and customer trust.

Features:

• 8” LCD touchscreen with 1280 x 800 resolution
• MaxiVCI V150 wireless adapter
• Full fault code reading and clearing for all available systems
• Real-time data display in statistical and graphical formats for easier interpretation
• Supports DoIP and CAN FD protocols
• AutoVIN technology for automatic identification of the vehicle's make, model, and year
• Pre- and post-fault scan report support
• Service interval and mileage reset
• Electronic parking brake release and position reset after brake pad replacement
• Forced DPF regeneration and injector calibration
• Battery registration and parameter reset supported
• Steering angle sensor parameter reset

Technical Specifications:

• Operating System: Android 11
• Processor: Quad-core 1.8 GHz
• RAM: 4 GB
• Storage: 64 GB ROM
• Display: 8” LCD touchscreen with 1280 x 800 resolution
• Camera: Rear-facing 8 MP
• Interfaces: USB Type C; USB 2.0; Wi-Fi; Bluetooth; Mini SD card (supports up to 64 GB)
• Audio Output: Speaker
• Battery: 3.7 V / 7700 mAh Li-ion
• Charger: 5V / 3A / DC
• Operating Temperature: 0°C to +50°C
• Storage Temperature: -10°C to +60°C
• Dimensions: 168.9 x 259.8 x 33.6 mm (W x H x D)
• Weight: 925 g
• Supported Protocols: ISO9141-2; ISO14230-2; ISO15765; K/L-Line; Flashing Code; SAE-J1850 VPW; SAE-J1850PWM; ISO11898 (High-speed, Middle-speed, Low-speed, and Single-wire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CANFD
• VCI Communication: BR + EDR
• VCI Wireless Frequency: 2.4 GHz
• VCI Input Voltage: 8 – 30 V DC
• VCI Power Consumption: 150 mA @ 12 V DC
• VCI Operating Temperature: 0°C to +50°C
• VCI Storage Temperature: -10°C to +60°C
• VCI Dimensions: 77.47 x 46.8 x 21.38 mm (L x W x H)
• VCI Weight: 51.5 g

Who Is This Device For?

• Autel MaxiDAS DS900BT is the perfect choice for professional auto repair shops, diagnostic workshops, and independent maintenance technicians seeking a fast, modern, and wireless solution for both routine and complex diagnostics. It combines speed and versatility with convenience and data accuracy.

Why Buy from Us?

• We are the exclusive official AUTEL distributor in Lithuania.
• Only original equipment with the widest data coverage in Europe.
• Built-in Russian and English languages.
• Fast delivery — 95% of items in stock.
• Option to test the device before purchase.
• Full warranty and post-warranty support.
• Free replacement device during repairs.

Save Time and Avoid Unnecessary Errors – with Smarter Equipment!

• Try the Autel MaxiDAS DS900BT — the wireless diagnostic tool that boosts efficiency and simplifies your work. Contact us now — we’ll help you choose the most suitable solution for your workshop!

COMPARISON TABLE
